PANASONIC Lumix S1R II Full-frame Mirrorless Digital Camera

Features
Type: DSLM (Digital Single Lens Mirrorless) camera
Lens mount accessory: L-Mount

Image sensor
Type: 35mm full-frame CMOS sensor (35.8mm x 23.9mm)
Effective camera pixels / Total pixels: 44.3 megapixels / 45.9 megapixels
Anti-reflective coating: ✓
Aspect ratio / Color filter: 3:2 / Primary color filter
Dust reduction system: Image sensor shift type
Shutter power-off behavior: ON / OFF

Photography
Recording file format: JPEG (DCF, Exif 3.0), RAW
Aspect ratio: 4:3 / 3:2 / 16:9 / 1:1 / 65:24 / 2:1
File size (pixels) / When using full-frame lenses:

3:2: 8144 x 5424 (L) / 5808 x 3872 (M) / 4128 x 2752 (S) / 1920 x 1280 (XS) / 16288 x 10848 (XL)* / 11504 x 7664 (LL)* *High resolution mode.

4:3: 7232 x 5424 (L) / 5168 x 3872 (M) / 3664 x 2752 (S) / 1712 x 1280 (XS) / 14464 x 10848 (XL)* / 10224 x 7664 (LL)* *High resolution mode.

16:9: 8144 x 4584 (L) / 5808 x 3272 (M) / 4128 x 2320 (S) / 1920 x 1080 (XS) / 16288 x 9168 (XL)* / 11504 x 6480 (LL)* *High resolution mode.
1:1: 5424 x 5424 (L) / 3872 x 3872 (M) / 2752 x 2752 (S) / 1280 x 1280 (XS) / 10848 x 10848 (XL)* / 7664 x 7664 (LL)* *High resolution mode.
65:24: 8144x3008 (W)
2:1: 8144x4072 (W)
File size (pixels) / When using APS-C:
3:2: 5360 x 3568 (W) / 3840 x 2560 (M) / 2688 x 1792 (S) / 1920 x 1280 (XS)
4:3: 4752 x 3568 (W) / 3424 x 2560 (M) / 2384 x 1792 (S) / 1712 x 1280 (XS)
16:9: 5360 x 3016 (W) / 3840 x 2160 (M) / 2688 x 1512 (S) / 1920 x 1080 (XS)
1:1: 3568 x 3568 (W) / 2560 x 2560 (M) / 1792 x 1792(S) / 1280 x 1280 (XS)
Image quality: RAW / RAW+Fine / RAW+Standard / Fine / Standard (High-resolution mode: Combined / RAW / RAW+Fine / Fine)
Color space: sRGB, AdobeRGB

Video
Recording file format: MOV: H.264/MPEG-4 AVC, H.265/HEVC, Apple ProRes, Apple ProRes RAW, MP4: H.264/MPEG-4 AVC, H.265/HEVC
4-channel audio recording: Off MOV: Linear format: LPCM (2-channel stereo 48 kHz/24-bit, 96 kHz/24-bit*), Floating format**: LPCM (2-channel stereo 48 kHz/32-bit, 96 kHz/32-bit), *When connecting 3.5mm F microphone or DMW-XLR2 model (sold separately). **With DMW-XLR2 model (sold separately).
MP4: Linear format: AAC (2-channel stereo 48 kHz/16-bit)
4-channel audio recording: XLR MOV: Linear format: LPCM (4-channel mono 48kHz/24-bit), Floating format: LPCM (4-channel mono 48 kHz/32-bit), *When connecting DMW-XLR2 model (sold separately).
4-channel audio recording: XLR* + MOV Camera: Linear format: LPCM (4ch mono 48 kHz/24-bit*, 96 kHz/24-bit**), *When connecting DMW-XLR2 (sold separately). **When connecting a 3.5mm F microphone or DMW-XLR2 (sold separately).
System frequency: 59.94 Hz / 50.00 Hz / 24.00 Hz
Video image area: Full / APS-C / PIXEL/PIXEL

Viewfinder
Type: OLED real-time viewfinder
Pixels: Approx. 5.76 million dots
Field of view / Magnification. Approx. 100 % / Approx. 0.78x with 50mm lens at infinity; -1.0 m¹, when the aspect ratio is set to 3:2
Focal point / Diopter adjustment: Approximately 21 mm at infinity; -1 m¹ / -4 - +2 (dpt)
Eye sensor: ✓
Display speed: 120 fps* / 60 fps *During real-time view in photo recording mode.

White Balance
White Balance: AWB / AWBc / AWBw / Day / Cloudy / Shade / Incandescent / Flash / White Adjustment 1, 2, 3, 4 / Color Temperature Setting 1, 2, 3, 4
White Balance Adjustment: Blue/Amber Bias, Magenta/Green Bias
Color Temperature Setting: 2500-10000K in 100K

Shutter
Type: Focal Plane Shutter
Silent Mode / Shutter Type: ✓ / ✓ (Auto / Mechanical / Electronic Front-curtain / Electronic / Electronic+NR)
Shutter Speed: Still: Bulb (maximum 30 minutes), 1/8000 - 60; Electronic front-curtain shutter: Bulb (maximum 30 minutes), 1/2000 - 60; Electronic shutter Image Priority mode: Bulb (maximum 60 seconds), 1/8000 - 60; Electronic shutter Speed Priority mode: Bulb (maximum 60 seconds), 1/16000 - 60; Video: 1/10000 - 1/25*; Video M mode / MF mode: 1/10000 - 1/2*; *To set the shutter speed higher than the frame rate, set the Shutter Speed ??Limiter function to off.
Self-timer: 10 sec., 3 frames / 2 sec. / 10 sec. / Custom duration
Remote control: Remote control model DMW-RS2 (sold separately)

Interval
AE range: 3, 5, 7 images in 1/3, 2/3 or 1 EV step, max. +/3 EV, single/continuous
Aperture range: 3, 5 or all positions
Focus range: ✓
White balance range: 3 images on the blue/amber axis or magenta/green axis, color temperature setting

Flash
Flash type: Sold separately
Sync speed: Less than 1/250 seconds *The guide number decreases at 1/250 seconds. In M mode or S mode only.
Flash mode: Auto* / Auto/Red-eye reduction* / Forced on / Forced on/Red-eye reduction / Slow sync / Slow sync/Red-eye reduction / Forced off *For iA only.
Flash output adjustment: 1/3 EV step ±3 EV
Flash sync: 1st-curtain sync, 2nd-curtain sync
Wireless control: ✓ (when using DMW-FL200L / FL360L / FL580L (sold separately)), wireless channel: 1 channel/2 channels/3 channels/4 channels

Image stabilization system
B.I.S.: 5-axis; Center: 8 steps; Peripheral: 7 steps; *Based on CIPA 2024 standard [Pitch/roll/rotate direction: Focusing distance f = 60 mm when using S-R2060.]
Dual I.S. 2: 5-axis; Center: 7 steps; Periphery: 7 steps; *Based on CIPA 2024 standard [Pitch/roll/rotate direction: Focusing distance f = 105 mm when using S-R24105.]

Rear monitor
Type: TFT LCD monitor with static touch control
Monitor size: Tilt-free angle, 3.0 in (7.6 cm), 3:2 aspect ratio
Pixels: Approx. 1.84 million dots
Field of view: Approx. 100%

Focusing
Type: Phased detection AF system / Contrast AF system
DFD technology: ✓
Focus mode: AFS (Single) / AFC (Continuous) / MF
AF mode: Tracking / Full-area AF / Zone (Horizontal/Vertical) / Zone / 1-Area+ / 1-Area / Pinpoint; *Auto Detection can be turned on to switch between Human / Animal / Car / Motorcycle / Bicycle / Train / Airplane. Except with One-point mode set. Focus Parts can also be set. AF detection range: EV -6 - 18 (F1.4, ISO100 equivalent, AFS)
AF Custom Setting: AF sensitivity, AF area change sensitivity, Object motion prediction
AF assist beam: ✓
AF lock: Set the Fn button in the custom menu to AF lock
Focus ring control: Non-linear / Linear (90°/ 120°/ 150°/ 180°/ 210°/ 240°/ 270°/ 300°/ 330°/ 360°/ 720°/ 1080°/ Max)
Others: AF-ON, AF-ON: Proximity shift, AF-ON: Distance shift, Focus limit, Focus peaking, Focus frame movement speed, Focus/Shutter priority, Focus shift vertical/horizontal focusing, AF/AE lock, AF+MF, MF assist, MF Guide, Focus ring lock, Show/hide AF mode, AF scope point, Shutter AF, Half-press shutter, Quick AF, Optical sensor AF, Loop focus frame, Magnified Live Viewfinder (video), AFS performance in video mode, Touch shutter, Touch AF/AE function, AF touch pad, Lens focus resume, AF micro adjustment

Zoom Function
Hybrid Zoom: Still image / Video
Crop Zoom: Still image / Video

Video Function
Time Lapse Shooting: ✓
Stop Motion Animation: ✓
Real Time Crop: ✓
SS/Gain Operation: Shutter Duration/ISO / Angle/ISO/Shutter Length/dB
Luminance Level: 8-bit: 0-255 / 16-235 / 16-255, 10-bit: 0-1023 / 64-940 / 64-1023
Master Pedestal Level: 31 steps
Color Bars/Test Tone: ✓ (SMPTE/EBU/ARIB)/✓
LUT Preview Aid: Monitor/HDMI
HLG Preview Aid: Monitor (MODE1/MODE2/OFF)/HDMI (AUTO/MODE1/MODE2/OFF)
Anamorphic Expand Preview: 2.0x/1.8x/1.5x/1.33x/1.30x/OFF
False Color: ✓
Scope/Vectorscope: Selectable
Knee stability: ✓ (in As 709 mode)
Other functions: Red frame recording indication, blue frame transmitting indication

TC In/Out
Count: Recording duration / Available time duration
Time code mode: Drop frame / No drop frame (with system frequency [59.94 Hz] selected.)
HDMI time code output: ON / OFF

Connectivity
Wi-Fi: 2.4 GHz bands (STA/AP) (IEEE802.11b/g/n), 5 GHz bands (STA/AP) (IEEE 802.11a/n/ac)
Security: WPA/WPA2/WPA3
Bluetooth: Bluetooth® v5.0 (Bluetooth Low Energy (BLE))

Supported dimensions and weight product
Dimensions (W x H x D): Approximately 134.3 x 102.3 x 91.8 mm (5.1 x 4.1 x 3.7 in) (body only, excluding protrusions)
Approximately 134.3 x 4.1 x 7.7 in (with S-R24105, excluding protrusions)
Weight: Approximately 795 g (body, flash shoe cover, battery, SD memory card x 1) (excluding body cap)
Approximately 712 g (body, flash shoe cover) (excluding body cap)
